1000W RF Power 20MHz 6000MHz Wireless Signal Jammer Vehicle Mounted

Product Description

1000W RF power Vehicle Mounted Jammer For Jamming 20-6000 MHz Wireless Communication

ZD-GR1000

The latest generation vehicle mounted jamming system

—— Low power,large range, all bands,no weakness, safer

  1.Description

ZD-GR1000 vehicle mounted jamming system can jam all the typical radio remote-control signal within frequency range of 20~6000MHz and stop activation of remote-control bombs. The system applies the state of art intelligent jamming and control technology in the industry. It accurately transmits jamming signal base on characteristics of target signal to achieve the best jamming effect. Especially, the technology improves jamming effect on walkie-talkie, 4G and 5G mobile communication signals. The system uses low transmitting power to cause large range jamming coverage. It also reduces the damage on users caused by high temperature and electromagnetic radiation.

The system’s core components apply fully digitalized circuit design. The antenna array is optimum designed for better reliability and practicality. The system really provides powerful technical support for anti-terrorism and public security staff.

     2.Applications

This jammer can be widely used by departments of police, anti-terrorism and country security protection.

• It can prevent activation of remote-controlled bombs and stop the terrorism activities.

¨ It can prevent terrorism attack and harassment of drones.

¨ For some VIP convoy, the system protects them during their traveling and ensures security of their parking area.

¨ For the emergency security protection during mass disturbances and large meeting, it can block the mobile signal in a large range to stop the extension of turbulence.

• When it is used in scenes of illegal gambling or sell drug, it can block mobile phone signal to stop the communication between criminals.
• When it is used in important department of country security and military, it can block wireless signal.

  3.Features

¨ The system pertinently jam remote-control links include remote-controller, walkie-talkie,2G/3G/4G/5G mobile communication,satellite telephone,WIFI,Bluetooth and so on；

¨ Extremely wide band jamming coverage. It can continuously jam radio signal in all the typical bands within 20-6000MHz；

¨ It can set allied frequency within jamming frequency bands to ensure ally communication during transmitting；

¨ Apply state of art mobile communication intelligent jamming technology in the industry；

¨ Outstanding jamming effect on walkie-talkie and mobile communication signals；

¨ Modular design. All channels can switch on/off individually；

¨ It has self-protection functions include protection of overheat, overvoltage, VSWR, short circuit and so on；

¨ Human-machine interaction design. User can rapidly operate the system on driver seat；

¨ Entity antenna design provides better integration. It allows vehicle to drive at high speed；

¨ Apply engine drive generator to be power supply. The system can work during vehicle driving.

  4.Technical specifications

¨ Frequency range:main bands in 20-6000MHz include remote-controller,walkie-talkie,drone,satellite telephone,2G/3G/4G/5G,WIFI signal, etc；

¨ Total average transmitting power:800W

¨ Jamming radius:³200m(typical value,transceiving distance of remote-controller≥100m,transceiving distance of walkie-talkie≥400m,mobile signal strength RSSI≤-65dBm,distance for different target is different)

¨ Antenna quantity:10

¨ Input voltage:AC220V or engine drive generator

¨ Continuously working time; more than 8 hours

¨ Main unit weight:£60Kg

¨ Main unit dimension(mm):550*480*600mm(L*W*H)

¨ Operation temperature:－20℃～55℃.

ZD-GR1000 vehicle mounted jamming system.doc
