Ip67 Lightweight Anti Drone Solutions Omni Detection

Ip67 Lightweight Anti Drone Solutions Omni Detection

Product Details:

Place of Origin: Jiaxing, Zhejiang, China
Brand Name: Zhejiang Zhongdeng Electronic Technology
Model Number: Hunting Eagle No1
Get Best Price Contact Now

Detail Information

Detection Distance: 5km Product Name: Stationary And Vehicle Mounted Drone Detection And Jamming System
Jamming Range: 2km Proof: IP67
Frequency Range: 0.8-6GHz Device Weight: 10kg
High Light:

ip67 anti drone solutions


lightweight anti drone solutions


omni detection drone detector

Product Description

Stationary and Vehicle mounted Anti Drone system with frequency 0.8-6GHz

---Omni detection/ Omni jamming /High detection height/Recognition




     1. Description

   In order to provide UAV protection solutions for vehicle convoy and target area, our company developed Hunting Eagle No1” UAV detection and jamming system(Stationary/Vehicle).

   It consists of detection subsystem and jamming subsystem. It has omni-directional detection function and omni-directional jamming function. The system includes the main frequency bands of popular drones. It can detect drones at height of 500m which enhance its tactical utility. It designed as small size. Both subsystems can work separately which makes the system deployment and transportation convenient. It is widely used for military, government department, power stations and so on.


       2. Functions

  • Accurate recognition:It recognizes type and unique electronic fingerprint of drone accurately and starts alert;
  • No duty people require:It can activate no duty people mode. Once drones are detected, the system will start alert automatically;
  • Black and white lists:The can mark drones on black and white lists. Drones on the white lists will not activate alert;
  • Easy for installation and deployment: The device can be installed on stationary rack for long term protecting of required area; It can also be installed on tripod for temporary applications during government conference, large rallies and so on.

  • Continuously work time:All day 24h with rain proof.

  • Extension ability:the system can be updated to add new drone detection bands;
  • Large frequency range: The system includes the main frequency bands of popular drones.

  • Omni-directional detection: The system equips omni-directional antenna for detection. It can detect drones at height of 500m.
  • Omni-directional jamming: The device has low radiation power so that it has raw effect on surrounding area; but it has many jamming frequency bands;


       3. Technical specifications


  • Detection distance:≥5km ( for ideal open place);
  • Operation voltage:AC220V±20%;
  • Device dimensions:Detection main unit F320mm´H360mm,
  • Jamming main unit:450´330´180mm;
  • Operation temperature:-40°~+55°C,
  • Proof:IP65.
  • Simultaneously detection drone quantity:≥30 drones;
  • Detection bands(MHz):845/868/900/2400/5800;
  •  Drone direction detection accuracy:≤15degree
  •  Detection sensitivity:better than -95dBm(25kHz);
  •  Device weight:Detection main unit:10Kg,
  • Jamming bands:800/900/1500/2400/5800;
  • Jamming radius:2km(for phantom 3,4);
  • Jamming main unit:16.5Kg;
